High Bandwidth Fibre Optic Patch Leads , Duplex Patch Cord Sc To Sc For CATV / Test
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Connector: | SC -SC | Jacket Material: | PVC |
|---|---|---|---|
| Fiber Type: | Duplex | Polish: | APC-APC |
SC APC to SC APC Duplex 2.0mm PVC(OFNR) 9/125 Single Mode Fiber Patch Cable
The 9/125μm single mode fiber optic cable meets RoHS compliant, and all cables are 100% optically tested for insertion loss to ensure high quality, it is very cost-effective for network cabling.
We also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.
| Connector | SC to SC | Jacket OD | 2.0mm |
| Fiber Mode | 9/125μm | Jacket Color | Yellow |
| Polish | APC to APC | Wavelength | 1310/1550nm |
| Fiber Type | Duplex | Jacket Material | PVC |
| Insertion loss | ≤0.3dB | Interchangeability | ≤0.2dB |
| Return loss | ≥60dB | Vibration | ≤0.2dB |
| Operating temperature | -40~75°C | Storage temperature | -45~85°C |
| Polarity | A(Tx) to B(Rx) | Fiber Grade | G652D |
Quality Certification
We are dedicated to providing customers with the outstanding, standards-compliant products and services.
We has passed many quality system verifications, like ISO9001 and RoHS, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service.
Product Highlights
Industry Standard Flammability Rating OFNR (Riser) Jacket Fiber Optic Cable
The industry standard duplex fiber connector meets EIA/TIA 604-2 with ceramic ferrule for high speed cabling networks.
Zirconia Ceramic Ferrule Optimum IL and RL
2.0mm Cable Boot, Provides Maximum Protection
Printing helps clarify and recognize different cables
