Product Details:
Place of Origin: Qingdao China
Brand Name: Sunet/OEM
Certification: ISO9001/ISO14001
Model Number: SNT-TB
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: USD 10-50/PCS
Packaging Details: Cartons
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000pcs/Day

24 Cores Drawer Type Fiber Optic Ftth Distribution Terminal Box

Description
Module Type: Drawer Type / Fixed Type Type: 12-144 Ports
Connector Type: SC/LC/FC/ST Color: Grey Or Black
Product Name: Ftth Distribution Terminal Box Material: Cold Rolled Steel/Galvanized Iron Plate
Application: FTTH FTTB FTTX Network Package: Carton

24 Cores Drawer Type Fiber Optic Ftth Distribution Terminal Box



Termination Box Description



Rack Mounted Patch Panel 19 Inch Fiber Optic Terminal Box is a kind of fiber optic management products used to distribute and protect the optical fiber links in FTTH Network. It is available for the distribution and terminal connection of various kinds of optical fiber system. These units are available in sizes that fit the most common distribution requirements. we provide is a kind of high quality, micro sized fiber optical termination box made of quality cold-rolled steel sheet and undergoes static plastic spraying treatment. The box can be installed in the indoor rack mount chassis and the indoor wall and terrace.



Termination Box Features



·Standard size, light weight and reasonable structure
·Can be used in 19'', 23'' standard distribution frame
·Suitable for ribbon and single fiber
·Various panel plate to fit different adapter interface
·24C, 36C, 48C, 72C optional, with or without fiber optic pigtail and adapter



Termination Box Application


·Telecommunications subscriber loop
·Fiber to the home (FTTH)
·LAN/WAN
·CATV



Termination Box Specifications



Product Name

Rack Mounted Patch Panel 19 Inch Fiber Optic Terminal Box

Module Type

Drawer Type / Fixed Type

Fiber Capacity of panel

12-144 core

Cable Type

SM MM OM3 OM4

Panel Connector

SC / LC / ST / FC

Dimension

430*220*44mm

Material

Cold Rolled Steel/Galvanized iron plate

Color

black or Grey

Work Temperature

-40~+85ºC

Cold-Rolled Steel Sheet Materials,thickness 1.0/1.2/1.5mm optional
